ARES TOP

Machine features

  • Tool carrier with RH and LH lateral hydraulic simultaneously widening with LH side cut-off, controlled by multifunction joystick through electrohydraulic distributor
  • RH and LH inter-row blades with multifunction joystick for electrohydraulic separately and simultaneously emergency blades return
  • Shutter kit, cast iron filter and flow diverter to feed the hydraulic system with 2 quick tractor couplings (minimum oil flow rate 55 l/min and maximum 95 l/min)
  • Double heat exchanger with thermostat and dedicated electrical control panel
  • Hydraulic set-up for application of driving accessories with PATENTED NO-STOP VALVES
  • Bulldozer-like tilling spurs
  • RH and LH toothed wheels for depth adjustment and side stability control
  • Available in version with front, rear or reversible three point frame


Contact request

Fille the form to get in touch.
The marked fields with * are required

Configurator

Select model

Modello Code Minimum power Widening Machine width Min width row Max width row Weight
Ares TOP 1S ART1S 50 25 + 25 104 / 154 144 204 435
Ares TOP 1 ART1 50 30 + 30 114 / 174 154 224 470
Ares TOP 2 ART2 50 40 + 40 130 / 210 170 260 505
Ares TOP 2X ART2X 50 50 + 50 135 / 235 175 285 525
Ares TOP 3 ART3 50 50 + 50 155 / 255 185 295 540
Ares TOP 4 ART4 50 50 + 50 197 / 297 237 347 575
Ares TOP 4X ART4X 50 100 + 100 247 / 447 277 487 610
Version




Blade/s


Industry 4.0

Select optionals

Code Description
Chassis with reversible 3-point chassis. The attachments work with 68-90cm adjustable axis. 1690

Chassis with reversible 3-point chassis. The attachments work with 68-90cm adjustable axis.

RH and LH inter-row hydraulic inclinations controlled by multifunction joystick. Overall dimensions cm 13cm. Applicable only when ordering. 2019

RH and LH inter-row hydraulic inclinations controlled by multifunction joystick. Overall dimensions cm 13cm. Applicable only when ordering.

Pair of patented RH and LH hydraulic ascent and descent systems with 20cm stroke controlled by multifunction joystick. Overall dimensions 20cm. Applicable only when ordering. 2022

Pair of patented RH and LH hydraulic ascent and descent systems with 20cm stroke controlled by multifunction joystick. Overall dimensions 20cm. Applicable only when ordering.

4m power cable (necessary for tractors without 3-pole female socket). 1190

4m power cable (necessary for tractors without 3-pole female socket).

Power cable 4m extension. 1411

Power cable 4m extension.

Extension 3m cable for 8-channel multi-function joystick. 1192

Extension 3m cable for 8-channel multi-function joystick.

Adding cost for RH and LH vulcanized rubber wheels with steel core installation (in substitution of standard wheels). 2035

Adding cost for RH and LH vulcanized rubber wheels with steel core installation (in substitution of standard wheels).

Push button for immediate RH rotary brush/mower head wire rotation stop. Applicable only when ordering. 1158

Push button for immediate RH rotary brush/mower head wire rotation stop. Applicable only when ordering.

Push button for immediate LH rotary brush/mower head wire rotation stop. Applicable only when ordering. 1159

Push button for immediate LH rotary brush/mower head wire rotation stop. Applicable only when ordering.

Adding cost for RH and LH installation hydraulic adjustments wheels controlled by multifunction joystick (applicable only when ordering). 2021

Adding cost for RH and LH installation hydraulic adjustments wheels controlled by multifunction joystick (applicable only when ordering).

RH blade with clod breaker, fin and feeler 45cm (additionally at the standard blade). 0982

RH blade with clod breaker, fin and feeler 45cm (additionally at the standard blade).

LH blade with clod breaker, fin and feeler 45cm (additionally at the standard blade). 0982/SX

LH blade with clod breaker, fin and feeler 45cm (additionally at the standard blade).

RH blade with clod breaker, fin and feeler 65cm (additionally to standard blade). 0695

RH blade with clod breaker, fin and feeler 65cm (additionally to standard blade).

LH blade with clod breaker, fin and feeler 65cm (additionally to standard blade). 0695/SX

LH blade with clod breaker, fin and feeler 65cm (additionally to standard blade).

RH blade with clod breaker, fin and feeler 85cm (additionally to standard blade). 0696

RH blade with clod breaker, fin and feeler 85cm (additionally to standard blade).

LH blade with clod breaker, fin and feeler 85cm (additionally to standard blade). 0696/SX

LH blade with clod breaker, fin and feeler 85cm (additionally to standard blade).

RH non-stop feeler pin holder. 1160

RH non-stop feeler pin holder.

LH no-stop feeler pin holder. 1161

LH no-stop feeler pin holder.

RH oscillating feeler pin holder adjustable in height. 1085

RH oscillating feeler pin holder adjustable in height.

LH oscillating feeler pin holder adjustable in height. 1086

LH oscillating feeler pin holder adjustable in height.

RH reinforced adjustable fender ground cover in special steel with wear-resistant interchangeable sled. It can't use contemporary with no-traction ploughshare RH. 1767

RH reinforced adjustable fender ground cover in special steel with wear-resistant interchangeable sled. It can't use contemporary with no-traction ploughshare RH.

Nota:

The codes 1767, 1405, 1046 e AARATROFR060 can be inserted in the configuration but the machine can be equipped with only one option at a time..

LH reinforced adjustable fender ground cover in special steel with wear-resistant. Cannot be used at the same time as the LH lifter plough kit code 0725. 1768

LH reinforced adjustable fender ground cover in special steel with wear-resistant. Cannot be used at the same time as the LH lifter plough kit code 0725.

Nota:

The codes 1047, 1768, 1406 e AARATROFR062 can be inserted in the configuration but the machine can be equipped with only one option at a time..

RH and LH extension for adjustable reinforced ground fender code 1767 or 1768. 1817

RH and LH extension for adjustable reinforced ground fender code 1767 or 1768.

RH shock absorber for RH adjustable and reinforced ground fender cover code 1046 or 1767. 1409

RH shock absorber for RH adjustable and reinforced ground fender cover code 1046 or 1767.

LH shock absorber for adjustable and reinforced ground fender cover code 1047 or 1768. 1410

LH shock absorber for adjustable and reinforced ground fender cover code 1047 or 1768.

RH kit adjustable ground fender cover with shock absorber complete with universal holder support for RH plant lifting plough kit with or without stump cleaner 2047

RH kit adjustable ground fender cover with shock absorber complete with universal holder support for RH plant lifting plough kit with or without stump cleaner

LH kit adjustable ground fender cover with shock absorber complete with universal holder support for LH plant lifting plough kit with or without stump cleaner 2048

LH kit adjustable ground fender cover with shock absorber complete with universal holder support for LH plant lifting plough kit with or without stump cleaner

RH ground fender with adjustable delimiter disc. Cannot be used at the same time as the LH lifter plough kit code 0702. 1405

RH ground fender with adjustable delimiter disc. Cannot be used at the same time as the LH lifter plough kit code 0702.

Nota:

The codes 1767, 1405, 1046 e AARATROFR060 can be inserted in the configuration but the machine can be equipped with only one option at a time..

LH ground fender with adjustable delimiter disc. Cannot be used at the same time as the LH lifter plough kit code 0725. 1406

LH ground fender with adjustable delimiter disc. Cannot be used at the same time as the LH lifter plough kit code 0725.

Nota:

The codes 1047, 1768, 1406 e AARATROFR062 can be inserted in the configuration but the machine can be equipped with only one option at a time..

RH stump cleaner for inter-row kit (remove the fixing plate when installing code 1247 RH vertical wires mower head). 1050

RH stump cleaner for inter-row kit (remove the fixing plate when installing code 1247 RH vertical wires mower head).

LH stump cleaner for inter-row kit (remove the fixing plate when installing code 1248 LH vertical wires mower head). 1051

LH stump cleaner for inter-row kit (remove the fixing plate when installing code 1248 LH vertical wires mower head).

RH sled for terrain with stones or superficial roots. 0483

RH sled for terrain with stones or superficial roots.

LH sled for terrain with stones or superficial roots. 1154

LH sled for terrain with stones or superficial roots.

RH 45cm inter-row plant lifting ploughshare. 1187

RH 45cm inter-row plant lifting ploughshare.

RH 45cm inter-row plant lifting ploughshare with specify stump cleaner. AVOMSQCDP007

RH 45cm inter-row plant lifting ploughshare with specify stump cleaner.

LH 45cm inter-row plant lifting ploughshare. 1188

LH 45cm inter-row plant lifting ploughshare.

LH 45cm inter-row plant lifting ploughshare with specify stump cleaner. AVOMSQCSP020 LH 45cm inter-row plant lifting ploughshare with specify stump cleaner.
RH 55cm inter-row plant lifting ploughshare. 1268

RH 55cm inter-row plant lifting ploughshare.

RH 55cm inter-row plant lifting ploughshare with specify stump cleaner. AVOMSCCDP019 RH 55cm inter-row plant lifting ploughshare with specify stump cleaner.
LH 55cm inter-row plant lifting ploughshare. 1269

LH 55cm inter-row plant lifting ploughshare.

LH 55cm inter-row plant lifting ploughshare with specify stump cleaner. AVOMSCCSP004 LH 55cm inter-row plant lifting ploughshare with specify stump cleaner.
RH plant lifting plough kit with front depth directional wheel. It cannot be used on front versions or at the same time as the RH ground fender cover code 1046, 1767 and 1405 0702

RH plant lifting plough kit with front depth directional wheel. It cannot be used on front versions or at the same time as the RH ground fender cover code 1046, 1767 and 1405

Nota:

The codes 1405, 1767, 1046 e 0702 can be inserted in the configuration but the machine can be equipped with only one option at a time..

LH plant lifting plough kit with front depth directional wheel. Cannot be used on front versions or at the same time as the LH fender ground code 1047, 1768 and 1406 0725

LH plant lifting plough kit with front depth directional wheel. Cannot be used on front versions or at the same time as the LH fender ground code 1047, 1768 and 1406

Nota:

The codes 1406, 1768, 1047 e 0725 can be inserted in the configuration but the machine can be equipped with only one option at a time..

RH plant lifting plough kit with front depth directional wheel and specify stump cleaner. It cannot be used on front versions or at the same time as the RH ground fender cover code 1046, 1767 and 1405 AARATROFR060

RH plant lifting plough kit with front depth directional wheel and specify stump cleaner. It cannot be used on front versions or at the same time as the RH ground fender cover code 1046, 1767 and 1405

Nota:

The codes 1767, 1405, 1046 e AARATROFR060 can be inserted in the configuration but the machine can be equipped with only one option at a time..

LH plant lifting plough kit with front depth directional wheel and specify stump cleaner. It cannot be used on front versions or at the same time as the RH ground fender cover code 1047, 1768 and 1406 AARATROFR062

LH plant lifting plough kit with front depth directional wheel and specify stump cleaner. It cannot be used on front versions or at the same time as the RH ground fender cover code 1047, 1768 and 1406

Nota:

The codes 1047, 1768, 1406 e AARATROFR062 can be inserted in the configuration but the machine can be equipped with only one option at a time..

RH no traction bulldozer-disk diameter 32cm. 0488

RH no traction bulldozer-disk diameter 32cm.

LH no traction bulldozer-disk diameter 32cm. 1157

LH no traction bulldozer-disk diameter 32cm.

Pair of adjustable no-traction universal rounded tiller discs diameter 36cm. 1267

Pair of adjustable no-traction universal rounded tiller discs diameter 36cm.

Pair of universal no traction adjustable ridger bit discs diameter 40cm. 1265

Pair of universal no traction adjustable ridger bit discs diameter 40cm.

RH no traction adjustable serrated ridger 2-discs diameter 40cm complete with cleaner on first disk. 1312

RH no traction adjustable serrated ridger 2-discs diameter 40cm complete with cleaner on first disk.

LH no traction adjustable ridger 2-discs diameter 40cm complete with cleaner on first disk. 1313

LH no traction adjustable ridger 2-discs diameter 40cm complete with cleaner on first disk.

RH starcut blade set with 2 stars. 1419

RH starcut blade set with 2 stars.

LH starcut blade set with 2 stars. 1420

LH starcut blade set with 2 stars.

RH starcut blade set with 3 stars. Code 1437 or 1665 must be applied. 1730

RH starcut blade set with 3 stars. Code 1437 or 1665 must be applied.

LH starcut blade set with 3 stars. 1731

LH starcut blade set with 3 stars.

RH fingerstar diameter 54cm for Expo complete with feeler and feeler pin holder (blue - hard). ASTARDEXD034

RH fingerstar diameter 54cm for Expo complete with feeler and feeler pin holder (blue - hard).

LH fingerstar diameter 54cm for Expo complete with feeler and feeler pin holder (blue - hard). ASTARDEXS009

LH fingerstar diameter 54cm for Expo complete with feeler and feeler pin holder (blue - hard).

RH fingerstar diameter 54cm (blue - hard). ASTARDEXD032

RH fingerstar diameter 54cm (blue - hard).

LH fingerstar diameter 54cm (blue - hard). ASTARDEXS007

LH fingerstar diameter 54cm (blue - hard).

Adapter for application of RH traction tools (15cm). 0657

Adapter for application of RH traction tools (15cm).

Adapter for application of LH traction tools. 1399

Adapter for application of LH traction tools.

RH vertical wires mower with adapter for Expo versions and wheel with mechanical adjustment for depth adjustment. Not available for model EXPO vers. S.  1247

RH vertical wires mower with adapter for Expo versions and wheel with mechanical adjustment for depth adjustment. Not available for model EXPO vers. S.

LH vertical mower head with adapter for Expo version and depth wheel with mechanical adjustment. Not available on model Expo vers. S. 1248

LH vertical mower head with adapter for Expo version and depth wheel with mechanical adjustment. Not available on model Expo vers. S.

RH mower head complete with adapter, feeler and feeler holder.  1818

RH mower head complete with adapter, feeler and feeler holder.

LH mower head short wires, complete with adapter, feeler and feeler holder.  1819

LH mower head short wires, complete with adapter, feeler and feeler holder.

RH hydraulic rotary brush with gear motor and oscillating adapter.  1150

RH hydraulic rotary brush with gear motor and oscillating adapter.

LH hydraulic rotary brush with gear motor and oscillating adapter.  1151

LH hydraulic rotary brush with gear motor and oscillating adapter.

RH traction mower head with blades or strings diameter 50cm. 0720

RH traction mower head with blades or strings diameter 50cm.

RH traction mower head with strings diameter 50cm. ATRBLDX053

RH traction mower head with strings diameter 50cm.

LH traction mower head with blades  diameter 50cm. 0720

LH traction mower head with blades  diameter 50cm.

RH traction mower head with strings diameter 50cm. ATRBLDX053

RH traction mower head with strings diameter 50cm.

RH traction mini-shredder head 60cm. 0718

RH traction mini-shredder head 60cm.

LH traction mini-shredder head 60cm. 1040

LH traction mini-shredder head 60cm.

RH traction rotary plant lifter with 4 shedding fins diameter 40cm. 1042

RH traction rotary plant lifter with 4 shedding fins diameter 40cm.

LH traction rotary plant lifter with 4 shedding fins diameter 40cm. 1044

LH traction rotary plant lifter with 4 shedding fins diameter 40cm.

Nr.2 kit to change the rotative plant lifter into a 40cm diameter 3-hoes cutter. 1108

Nr.2 kit to change the rotative plant lifter into a 40cm diameter 3-hoes cutter.

RH traction rotary plant lifter with 4 shedding fins diameter 50cm. 1043

RH traction rotary plant lifter with 4 shedding fins diameter 50cm.

LH traction rotary plant lifter with 4 shedding fins diameter 50cm. 1045

LH traction rotary plant lifter with 4 shedding fins diameter 50cm.

Nr. 2 Kit to transform the rotary plant lifter in cutter 50cm diameter to 4 hoes. 1099

Nr. 2 Kit to transform the rotary plant lifter in cutter 50cm diameter to 4 hoes.

RH circular cutter hydraulic kit for 55cm or 65cm inter-row blade. 1637

RH circular cutter hydraulic kit for 55cm or 65cm inter-row blade.

LH circular cutter hydraulic kit for 55 or 65cm inter-row blade.  1672

LH circular cutter hydraulic kit for 55 or 65cm inter-row blade.

RH traction 3-hoes hydraulic circular cutter diameter 25cm complete with low engine for limited inter-row work. 1403

RH traction 3-hoes hydraulic circular cutter diameter 25cm complete with low engine for limited inter-row work.

LH traction 3-hoes hydraulic circular cutter diameter 25cm complete with low engine. AFRECDCSX002

LH traction 3-hoes hydraulic circular cutter diameter 25cm complete with low engine.

RH traction 3-hoes hydraulic circular cutter diameter 40cm with brush. AFRECSQDX011

RH traction 3-hoes hydraulic circular cutter diameter 40cm with brush.

LH traction 3-hoes hydraulic circular cutter diameter 40cm with brush. AFRECSQSX005

LH traction 3-hoes hydraulic circular cutter diameter 40cm with brush.

RH traction 3-hoes hydraulic circular cutter diameter 40cm with engine. AFRECQCDX025

RH traction 3-hoes hydraulic circular cutter diameter 40cm with engine.

LH traction 3-hoes hydraulic circular cutter diameter 40cm. AFRECQCSX005

LH traction 3-hoes hydraulic circular cutter diameter 40cm.

Nr. 2 kit to change the cutter into a rotative plant lifter 40cm diameter to 4 fins. 1295

Nr. 2 kit to change the cutter into a rotative plant lifter 40cm diameter to 4 fins.

RH traction 4-hoes hydraulic circular cutter diameter 50cm. AFRECCCDX013

RH traction 4-hoes hydraulic circular cutter diameter 50cm.

LH traction 4-hoes hydraulic circular cutter diameter 50cm. AFRECCCSX006

LH traction 4-hoes hydraulic circular cutter diameter 50cm.

Nr.2 Kit to change the circular cutter into a rotative plant lifter 50cm diameter to 4 fins. 1294

Nr.2 Kit to change the circular cutter into a rotative plant lifter 50cm diameter to 4 fins.

RH traction 2-lifting disc 36cm diameter. 1289

RH traction 2-lifting disc 36cm diameter.

LH traction 36cm diameter 2-lifting disc. 1288

LH traction 36cm diameter 2-lifting disc.

RH traction disk set with 3 plant lifting disks diameter 36cm. 0717

RH traction disk set with 3 plant lifting disks diameter 36cm.

LH traction disk set with 3 plant lifting disks diameter 36cm. 1038

LH traction disk set with 3 plant lifting disks diameter 36cm.

RH stump cleaner on 2/3/4 traction disk set plant lifting disks diameter 36cm. 1384

RH stump cleaner on 2/3/4 traction disk set plant lifting disks diameter 36cm.

LH stump cleaner on traction disk set with 2/3/4 plant lifting disks diameter 36cm. 1402

LH stump cleaner on traction disk set with 2/3/4 plant lifting disks diameter 36cm.

RH disk traction driving toothed disk diameter 40cm with working angle register.  1371

RH disk traction driving toothed disk diameter 40cm with working angle register.

LH disk traction driving toothed disk diameter 40cm with working angle register.  1372

LH disk traction driving toothed disk diameter 40cm with working angle register.

RH 2 kit disks traction driving toothed disks diameter 40cm with working angle register.  1777

RH 2 kit disks traction driving toothed disks diameter 40cm with working angle register.

LH 2 kit disks traction driving toothed disks diameter 40cm with working angle register.  1778

LH 2 kit disks traction driving toothed disks diameter 40cm with working angle register.


The marked fields with * are required

Table form

Model Code Minimum power Widening Machine width Min width row Max width row Weight
Ares TOP 1S ART1S 50 25 + 25 104 / 154 144 204 435
Ares TOP 1 ART1 50 30 + 30 114 / 174 154 224 470
Ares TOP 2 ART2 50 40 + 40 130 / 210 170 260 505
Ares TOP 2X ART2X 50 50 + 50 135 / 235 175 285 525
Ares TOP 3 ART3 50 50 + 50 155 / 255 185 295 540
Ares TOP 4 ART4 50 50 + 50 197 / 297 237 347 575
Ares TOP 4X ART4X 50 100 + 100 247 / 447 277 487 610
